DuraRack - Indoor / Outdoor Enclosure

DuraRack – Indoor / Outdoor Enclosure

0 (0) Reviews

DuraRack – Indoor / Outdoor Enclosure

Description


Expand your energy storage with the Fortress Power DuraRack. This iron enclosure stores up to 4 eFlex 5.4kWh batteries, and is expandable up to 4 units (15 eFlex batteries, 81KWh). The DuraRack includes integrated busbars, wheels, and a DIN rail heater mount. This enclosure can be free-standing or pad mounted and is safe for indoor and outdoor installations.

  • IP65 WATER AND DUST RESISTANT FOR BOTH INDOOR AND OUTDOOR INSTALL
  • INCLUDES INTERGRATED BUSBARS AND BATTERY CABLES FOR EASY STACKING
  • EASY TO ADD DIN RAIL THERMOSTAT FOR COLD CLIMATES
  • PASSIVE COOLING VENT FOR WARM CLIMATES
  • BUILT ON WHEELS FOR EASY MOVEMENT AND POSITIONING
  • EXPANDABLE UP TO 4 UNITS (15 EFLEX BATTERIES; TOTAL 81 KWH)
Category:

Product Info

Browse our Applications

Reliable source of renewable energy
you can trust to deliver off-grid living.

REQUEST ADDITIONAL INFO

Where to buy?

Browse our distribution partners worldwide.
High quality battery backup solutions.

BROWSE DISTRIBUTORS

How to become a dealer?

Enroll now to become a dealer.
Get free leads and marketing help.

BECOME A DEALER

DuraRack Specifications
Enclosure Material Carbon Steel
Enclosure Protection IP65 water and dust proven (outdoor)
Enclosure Color White
Dimensions [W x H x D] 29.29 x 41.34 x 18.03 in (744 x 1050 x 458 mm)
Enclosure Weight 59.6 kg / 153.2 lbs
Maximum Battery Units 4 eFlex 5.4
Storage Capacity Range 5.4kWh - 21.6 kWh per unit
Max. Storage Capacity 81 kWh (4 unites in parallel)
Knockout Size 1inch & 2 inch
Positive and Negative Battery Busbars 2 x 4 points; M8 (5/16) Terminal Rings
Positive and Negative Busbars to Inveter 2 points; m10 (3/8) Terminal Rings
Battery Cables 4 sets of
Terminal Torque 7.0 - 7.7 Nm (5.1 - 5.7 ft-lb)
Enclosure Warranty 3 Years
Certifications UL9540, UL9540A, UL1973, CEC, SGIP
